MSE Sampler

Download Specs

Email Specs

Get Started

Request A Quote

Not What You're Looking For?

Designed for high viscosity applications such as toothpaste, peanut butter, and concentrates, the ISOLOK MSE high viscosity sampler ensures that your samples are representative of your entire food and beverage process. This automatic sampler's contracting annulus and sanitary construction ensure that you are meeting the demands of your processes and isolating the sample from human bias. By handling pressures up to 150 psi, the ISOLOK sampler's design is addaptable to a mutlitude of applications without limiting its functionality.

This high viscosity sampler captures 10 cc per cycle
Uses two-inch tri-clamp ferrule mount help with a clamp and gasket to adapt to already in place equipment.
A variety of customizations are available from port closures, line adapters, different containers. and more.

Download Specs

Email Specs

Sample volume per cycle	10 cc
Maximum cycle frequency	6 strokes per minute, depending on application
Line mounting options	Tri-clamp
Materials	316 stainless steel/Buna-N; other seal materials available
Sample temperature range	-40° to 500°F (-40° to 260°C), depending on seal material and duty cycle
Ambient operating temperature range	-5° to 131°F (-20° to 55°C), depending on seal material
Compressed air requirement	2 SCFM at 90 psi (.05 m³/min at 6.2 bar)
Dimensions	10.3 in x 4 in (26 cm x 10 cm)
Shipping weight	16.6 lb (7.5 kg)
