Designed for sampling powders, flakes, and pellets, the ISOLOK SAH sampler ensures that your samples are represeantative of your entire process

Designed for sampling powders, flakes, and pellets, the ISOLOK SAH sampler ensures that your samples are represeantative of your entire process. This automatic sampler usesa three-inch stroke cylinder to obtain samples from heavy walled vessels such as mixers, dryers, and reactors.
The ISOLOK sampler's design uses compressed air to grab a fixed amount pf product at set intervals. The product is then discharged by gravity to a sampler container. This ensures that your sample is not only representative of the entire batch but also allows for inline batch control.

The SAK powder sampler is designed to capture a 16 or 18cc sample, making it adaptable to sampling requirements.
The sampler is available in versatile seal options to meet your process needs.
Handles powder, flakes, and pellets up tp 5/8 inch (16mm) without shearing or degradding sample material.

Download Specs

Email Specs

Sample volume per cycle	40 or 50 cc
Maximum particle size	0.62 in (16 mm)
Maximum cycle frequency	12 strokes per minute, depending on application
Materials	316 stainless steel; other materials available
Actuator seal	filled Teflon®; other materials available
Static seals	fluoroelastomer; other materials available
Plunger seals	filled Teflon, polyurethane, EPDM rubber, other materials available
Sample temperature range	-40°F to 575°F (-40°C to 302°C), depending on seal material and duty cycle
Ambient operating temperature range	-5° to 131°F (-20° to 55°C) depending on seal material
Line mount adapter type	2.5 in (63 mm) clamp ferrule
Compressed air requirement	2 SCFM at 30 to 80 psig (2.1 to 5.5 barg)
Dimensions	14.7 in x 3 in (373 mm x 76 mm)
Shipping weight	21 lb (9.5 kg)
