Designed for thick slurries such as raw municiple sludge and waste acidsd, the ISOLOK SAG slurry sampler ensures that your samples are representative of your entire process and operators are protected from potentially hazardous products.
Designed for thick slurries such as raw municiple sludge and waste acidsd, the ISOLOK SAG slurry sampler ensures that your samples are representative of your entire process and operators are protected from potentially hazardous products. This automatic sampler is made with 316 Stainless Steel components to meet different process applications.
The ISOLOK sampler's design uses compressed air and a controller to force a plunger into up to 300 psi (2.7 bar) pressurized processes fro complete representative sampling.
The ISOLOK sampler's design uses compressed air and a controller to force a plunger into up to 300 psi (2.7 bar) pressurized processes fro complete representative sampling.
- The ISOLOK SAG sampler has a variety of options such as port closures, differnt container types, sampler enclosures, etc.
- The modulat slurry design is available with three different models for sampling fixed volumes of 50 cc, 120 cc or 200 cc per sample cycle.
| Sample volume per cycle | 120 or 200 cc |
| Maximum cycle frequency | 6 strokes per minute, depending on application |
| Maximum particle size | 1/4 in (6.3 mm) | 5/8 in (16 mm) | 7/8 in (22 mm) |
| Line mounting options | MNPS thread, tri-clamp, instrument hub, bolted hub 2, ANSI flange |
| Materials | 316 stainless steel; other materials available |
| Cylinder seals | Halar®, TFE or custom |
| Plunger seals | TFE, polyurethane, EPDM rubber, Kalrez® or custom |
| Compressed air requirement | 2 SCFM at 90 psi (.05 m³/minimum at 6.2 bar) |
| Dimensions | 16.69 in x 6 in (42.4 cm x 15.25 cm) |
| Shipping weight | 58 to 66 lb (26.3 to 30 kg) |
