Obtain samplessafely from continuously pressurized process lines with the ISOLOK SAL-B sampler. Desined for lliquid and slurry applications, the SAL-B can handle processes of up to 300 psi (20.7 bar) and particles up to 3/8 inches (9 mm). The sampler is built with 316 stainless stell and tough, hardened 17-4PH to ensure that iit can stan dup to abrasive materials such as sand and gravel sllurry tailings.

Due to these high demands, the sampler comes with an ISOVALVE and seperate closure plate as standard to ensure that the sampler can be isolated and removed from the process line while it is under pressure. The sampler als has telltale ports on thhe isolation valve for verification of depressurization to ensure operator safety.

Remain confident in your sample's representation with the continuous pressure sampler's optional parl position cylinder that prevents product accumulation and wear.
A variety of customizations are available from various seal materials, port closures, line adapters, different containers, and more.

Download Specs

Email Specs

Sample volume per cycle	8 or 25 cc
Maximum cycle frequency	10 strokes per minute for non-park position samplers; 6 strokes per minute for park position samplers, depending on application
Maximum particle size	3/8 in. (9 mm)
Line mounting options	bolted hub
Materials	316 and 17-4PH stainless steel
Actuator and static seals	Filled PTFE and fluoroelastomer
Plunger seals	Polyurethane, EPDM, Kalrez®, PTFE, NBR or custom
Compressed air requirement	2 SCFM at 90 psi (.05 m³/minimum at 6.2 bar)
Operating pressure recommended range	300 psig (20.7 bar) process at 80 psig (5.5 barg) air
Dimensions	15.875 in. l x 6 in. d (40 cm. x 15.25 cm.) for non-park samplers 20.813 in. l x 6 in. d (52.8 cm. x 15.25 cm.) for park samplers
Shipping weight	33 lbs. (15 kg.) for non-park samplers; 45 lbs. (20 kg.) for park samplers
